Description
The Panasonic FC Series 220µF 35V Aluminum Electrolytic Capacitor is available in a pack of five (Part # EEU-FC1V221L). These radial-lead capacitors feature low impedance, high ripple current handling, and consistent performance within an 8mm x 15mm size. They are designed for mid-voltage circuits requiring moderate capacitance for filtering and power stabilization in compact configurations, with a focus on automotive and industrial applications.
Key Features:
Capacitance: 220µF – Suitable for moderate energy storage and voltage smoothing.
Voltage Rating: 35V – Compatible with circuits up to 30V, including 12V and 24V systems.
Tolerance: ±20% – Ensures reliable operation across various conditions.
Low ESR: The FC series provides reduced impedance, contributing to lower heat generation and improved efficiency.
High Ripple Current: Rated at 665mA, capable of handling load fluctuations in power circuits.
Lifespan: Rated for up to 2000 hours at 105°C, supporting typical usage durations in demanding environments.
Radial Design: 8mm diameter x 15mm height with a 5mm lead pitch, fitting standard PCB layouts.
Polarized: Marked to indicate proper installation orientation.
Common Applications:
Power Supply Filtering: Stabilizes voltage in 12V–30V power supplies, such as automotive electronics or industrial equipment.
Decoupling: Maintains steady power for microcontrollers, sensors, or amplifiers in mid-voltage systems.
Audio Systems: Reduces noise in amplifiers or audio devices operating within 35V limits.
LED Drivers: Supports consistent current in 12V–30V LED circuits.
Electronics Repair: Acts as a replacement for capacitors in power boards, automotive modules, or consumer devices.
About Panasonic FC Series:
The FC series is characterized by low impedance and high reliability, tailored for applications requiring durability under vibration and temperature stress, such as automotive and industrial uses. This five-pack serves as a practical option for repairs, prototyping, or circuit applications requiring dependable performance, reflecting Panasonic’s engineering standards.
Specifications:
Brand: Panasonic
Series: FC
Capacitance: 220µF
Voltage: 35V DC
Tolerance: ±20%
Dimensions: 8mm (D) x 15mm (H)
Lead Spacing: 5mm
Operating Temperature: -40°C to +105°C
Quantity: 5 pieces per pack
Quality Assurance:
Pacific Custom Engineering supplies genuine Panasonic components, ensuring consistent performance for a range of circuit uses.
Data Sheet:https://pacificcustomengineering.com/wp-content/uploads/2023/09/ABA0000C1209.pdf
