Description
The Panasonic FR Series 47µF 63V Aluminum Electrolytic Capacitor is available in a pack of six. These radial-lead capacitors feature ultra-low ESR, high ripple current handling, and reliable performance in a 6mm x 11mm size. They are designed for high-voltage, low-capacitance applications requiring efficient power management in compact circuits.
Key Features:
Capacitance: 47µF – Perfect for light filtering and signal coupling.
Voltage Rating: 63V – Suited for circuits up to 60V, including 48V and 24V systems.
Ultra-Low ESR: FR series delivers minimal impedance for reduced heat and superior efficiency.
High Ripple Current: Handles demanding loads with ease, ideal for power-intensive circuits.
Extended Lifespan: Rated for up to 10,000 hours at 105°C, ensuring long-term durability.
Compact Radial Design: 6mm diameter x 11mm height with a 2.5mm lead pitch, fitting tight PCB layouts.
Polarized: Clearly marked for quick, precise installation.
Common Applications:
Power Supply Filtering: Smooth voltage ripples in 24V–60V switching power supplies or industrial equipment.
Coupling: Pass AC signals while blocking DC in high-fidelity audio preamps or signal circuits.
Decoupling: Stabilize power in sensitive electronics like sensors, amplifiers, or control modules.
Audio Systems: Enhance sound quality in amplifiers or Hi-Fi setups with low-noise performance.
Electronics Repair: Upgrade capacitors in power boards, LED drivers, or modern devices with a high-performance option.
Why Panasonic FR Series?
The FR series is engineered for ultra-low ESR and high endurance, outperforming standard electrolytic capacitors with up to 50% lower impedance and double the lifespan of many alternatives. This six-pack is a cost-effective choice for repairs, prototyping, or high-reliability builds, backed by Panasonic’s cutting-edge technology.
Specifications:
Brand: Panasonic
Series: FR
Capacitance: 47µF
Voltage: 63V DC
Dimensions: 6mm (D) x 11mm (H)
Lead Spacing: 2.5mm
Operating Temperature: -40°C to +105°C
Quantity: 6 pieces per pack
Quality Assurance:
Pacific Custom Engineering supplies genuine Panasonic components, ensuring consistent performance for various circuit uses.
Data Sheet: https://pacificcustomengineering.com/wp-content/uploads/2024/01/ABA0000C1259.pdf
