[BULK] 100 x ESP32-CAM ESP32-CAM-MB 5V WIFI Bluetooth Development Board CH340G /OV2640 Camera
[BULK] 100 x ESP32-CAM ESP32-CAM-MB 5V WIFI Bluetooth Development Board CH340G /OV2640 Camera - Image 2
[BULK] 100 x ESP32-CAM ESP32-CAM-MB 5V WIFI Bluetooth Development Board CH340G /OV2640 Camera - Image 3
[BULK] 100 x ESP32-CAM ESP32-CAM-MB 5V WIFI Bluetooth Development Board CH340G /OV2640 Camera - Image 4

[BULK] 100 x ESP32-CAM ESP32-CAM-MB 5V WIFI Bluetooth Development Board CH340G /OV2640 Camera

$1,399.00

The ESP32-CAM-MB module is a small camera module with a size of 39.8mm x 27mm. This module can work independently as the smallest system.
This particular item is customized with:
  • A2SHB MOSFET Flash LED Driver.
Factory Lead Time: 3 weeks.
A new WiFi+Bluetooth dual-mode development board based on ESP32 design, using PCB on-board antenna, with 2 high-performance 32-bit LX6CPU, using 7-level pipeline architecture, main frequency adjustment range 80MHz to 240Mhz.
Ultra-low power consumption, deep sleep current is as low as 6mA.
It is an ultra-small 802.11b/g/n Wi-Fi + BT/BLE SoC module ESP32-CAM-MB adopts Micro USB interface, convenient and reliable connection method, convenient to apply to various IoT hardware terminal occasions.

Out of stock

SKU: esp32-cam-esp32-cam-mb-5v-wifi-bluetooth-development-board-ch340g-ov2640-camera-1 Category:

Description

Fast and Free Shipping from Washington State
Basic performance parameters:
1. Use low-power dual-core 32-bit CPU, which can be used as an application processor.
2. The main frequency is up to 240MHz, and the computing power is up to 600 DMIPS
3. Built-in 520 KB SRAM, external 8MB PSRAM
4. Support UART/SPI/I2C/PWM/ADC/DAC and other interfaces
5. Support OV2640 and OV7670 cameras, built-in flash
6. Support picture WiFI upload
7. Support TF card
8. Support multiple sleep modes.
9. Embedded Lwip and FreeRTOS
10. Support STA/AP/STA+AP working mode
11. Support Smart Config/AirKiss one-click network configuration
12. Support secondary development
Application scenarios
1. Home smart device image transmission
2. Wireless monitoring
3. Smart agriculture
4. QR wireless recognition
5. Wireless positioning system signal
6. And other IoT applications
Parameter Description
Working Voltage 4.75-5.25V
SPIFlash Default 32Mbit
RAM Internal 520KB+ 8MB PSRAM
Wi-Fi 802.11b/g/n/e/i
Bluetooth Bluetooth 4.2BR/EDR and BLE standard
Supported interface

（2Mbps）

 UART、SPI、I2C、PWM
Support interface

TF Card

 Max. 4G
IO Port 9
Serial port rate Default 115200bps
Spectrum range 2400-2483.5MHz
Antenna form Onboard PCB Antenna , Antenna Gain 2dBi
Image output format JPEG(Only OV2640 Support),BMP,GRAYSCALE
Packaging method DIP-16
Transmit power 802.11b:17±2dBm (@11Mbps)

802.11g:14±2dBm (@54Mbps)

802.11n:13±2dBm (@MCS7)
Receiving sensitivity CCK,1Mbps:-90dBm

CCK,11Mbps:-85dBm

6Mbps(1/2BPSK):-88dBm

54Mbps(3/464-QAM):-70dBm

MCS7(65Mbps,72.2Mbps):-67dBm
Power consumption Turn off the flash:180mA@5V

Turn on the flash and adjust the brightness to maximum:310mA@5V

Deep-sleep:Minimum 6mA@5V

Moderm-sleep:Minimum 20mA@5V

Light-sleep:Minimum 6.7mA@5V
Safety WPA/WPA2/WPA2-Enterprise/WPS
Operating temperature -20 ℃~ 70 ℃
Storage environment -40 ℃~ 125 ℃, < 90%RH
weight 10g

Discover more from Pacific Custom Engineering

Subscribe to get the latest posts sent to your email.

Additional information

Brand

Pacific Custom Engineering
MPN

PCE-ESP-32-A2SHB
GTIN

818265852698
